Cisco SFP-10G-LR-S Compatible 10GBASE-LR SFP+ Transceiver Module (SMF, 1310nm, 10km, LC, DOM)
The Cisco SFP-10G-LR-S compatible SFP+ optical transceiver is equipped with an LC duplex connector, reaching a link up to 10km over OS2. QSFPTEK manufactured 10GBASE-LR SFP+ transceiver module is compliant with SFP+ MSA, IEEE 802.3ae, SFF-8472. Besides, DDM (digital diagnostics monitoring) function is supported on the 10G fiber optic transceiver to achieve real-time operating parameters monitoring. This 10G SFP+ transceiver is applied in various application scenarios such as data centers, campus networks. It’s also fully compatible with almost all Cisco devices.
| Model Name: | SFP-10G-LR-S | Vendor Name: | QSFPTEK |
| Form Factor: | SFP+ | Data Rate: | 10Gbps |
| Wavelength: | 1310nm | Distance: | 10km@G.652 |
| Connector: | LC Duplex | Cable Type: | OS2 SMF |
| Transmitterr Type: | DFB | Receiver Type: | PIN |
| TX Power: | -6.5~-0.5dBm | Receiver Sensitivity: | <-12.6dBm |
| Power Consumption: | <0.8W | Modulation Format: | NRZ |
| DDM: | Support | Bit Error Ratio (BER): | 1.00E-12 |
| Protocols: | IEEE 802.3ae, SFF-8472 | Warranty: | 3 Years |
Quality Certifications
Features
| 1. High Reliablility and Best Price
Proudly self-producing and rigorous testing, QSFPTEK is dedicated to delivering cost-effective products with high reliability and performance at trade price. |
2. Wide Application Scenarios
Ideal for data center, campus network and 40G-10G Break-out |
| 3. Protocols
Compliant with IEEE 802.3ae, SFF-8472, SFF-8431, SFF-8432. |
4. Quality Certifications
Backed by CE, FCC, ROSH, ISO9001. |
Applications
Scenario 1: 10G Switch to 10G Switch Direct Connectivity
Scenario 2: 10G Switch to 10G NIC Direct Connectivity
Scenario 3: 40G to 10GBASE-LR Breakout Connectivity
Product details
Various Switch Tests
Every module is quality tested for compatibility in the multi-brand switches environment, which guarantees flawless operations.
Tested in The Host Device to Prove Interoperability
Every unit sold undergoes rigorous quality testing, to ensure compatibility in the target switch environment, guaranteeing perfect operation.
Comprehensive Testing
Every module is qualified through rigorous procedures and advanced equipment to ensure high-quality and reliable optical devices for you.
10G SFP+ Model Contrast Table
| Part Number | QT-SFP+-T
QT-SFP+-IT |
QT-SFP+-T-80 | QT-SFP+-SR | QT-SFP+-IR | QT-SFP+-LR | QT-SFP+-LH | QT-SFP+-ER | QT-SFP+-ZR | QT-SFP+-ZR+ |
| Image |  |
 |
 |
 |
 |
 |
 |
 |
 |
| Wavelength | — | — | 850nm | 1310nm | 1310nm | 1310nm | 1550nm | 1550nm | 1550nm |
| Max Distance | 30m@Cat6a/7 | 80m@Cat6a/7 | 300m | 2km | 10km | 20km | 40km | 80km | 100km |
| Cable Type | Copper | Copper | OM3/OM4 MMF | OS2 SMF | OS2 SMF | OS2 SMF | OS2 SMF | OS2 SMF | OS2 SMF |
| Connector | RJ45 | RJ45 | LC Duplex | LC Duplex | LC Duplex | LC Duplex | LC Duplex | LC Duplex | LC Duplex |
| Tx Power(dBm) | — | — | -6.5~-0.5 | -8.2 ~ -0.5 | -6.5~-0.5 | -6~-1 | -2~4 | 0 ~ 5 | 1 ~ 5 |
| Rx Sensitivity(dBm) | — | — | -11.1 | -12.6 | -12.6 | -14.4 | -15.8 | -24 | -25 |
| Power Consumption | <2.5W | <2.5W | <0.8W | <0.8W | <0.8W | < 1W | <1.5W | <1.5W | <1.5W |
| Source | — | — | VCSEL + PIN | FP + PIN | DFB + PIN | DFB + PIN | EML + PIN | EML + APD | EML + APD |
| Operating Temperature | 0 to 70°C
-40 to 85°C (IND) |
0 to 70°C | 0 to 70°C | 0 to 70°C | 0 to 70°C | 0 to 70°C | 0 to 70°C | 0 to 70°C | 0 to 70°C |
